RC28 Team Kit

RC28 Team Kit

$249.99
You save $118.00
MSRP: $367.99
SKU:
20165
UPC:
784695201651
Maximum Purchase:
5 units
Out of stock
Manuals/Documents
RC28R Team Kit


RC28 Team Kit

1:28 Scale 2WD Electric On-Road Competition Kit

Introducing the Team Associated RC28R Team Kit. This compact on-road race car is designed with the same engineering precision found in every AREA 51-developed product. Though small in scale, the RC28R delivers big performance in an easy to set up package. Featuring a fixed-arm front suspension with included optional molded upper arms for tuning caster and camber. The torsion side links (soft, medium, and hard included) replace the need for a side spring making setup easy while adding performance in areas a conventional spring does not. The battery holder design ensures quick access without disturbing the center shock.
The steel chassis plate provides a low center of gravity while the insert adjustable roll center enables chassis roll adjustment based on the grip level. The pitch, roll and droop can further be tuned/Adjusted with the threaded aluminum center shock, spring collars and side damper tubes. The two-piece rear pod allows quick axle height adjustment utilizing Factory Team carbon fiber shims. Fine-tune Ackermann on the fly with the adjustable servo mount. Compact, tunable, and designed to race, the RC28R is built for high performance and fun—even in tight spaces.

Features

  • Steel chassis plate for low center of gravity
  • Fixed arm style front end with optional molded upper arms to adjust caster and camber
  • Front bulkhead design allows for quick upper arm changes with consistent fitment and position
  • Optimized steering geometry with adjustable servo mount to tune ackerman on the fly
  • Easily removable battery holder to access the battery without removing center shock
  • Torsion style side links act as side spring with soft, medium, and hard options included
  • Adjustable rear pod roll center inserts to tune roll characteristics to grip level
  • Optimized roll geometry with side damper tubes
  • Threaded aluminum center shock with adjustable droop and spring collar
  • Two-piece rear pod with adjustable axle heights for different tire diameters and ride heights utilizing Factory Team carbon fiber shims
  • Gear differential included and can fit other aftermarket options currently available
  • Hard plastic and polycarbonate body mounting options included
  • White wheels included that fit optional front wheel flanges to tune steering feel
  • Universal front bumper included

Not Included: Body

Other Helpful Items

  • Silicone Shock Fluid (Refer to catalog for complete listings)
  • Silicone Diff Fluid (Refer to catalog for complete listings)
  • Body Scissors (AE Part # 1737)
  • Reamer / Hole Punch
  • FT Wrench Set (AE Part #1519)
  • Hobby Knife
  • Needle Nose Pliers
  • Wire Cutters
  • Soldering Iron
  • Calipers or a Precision Ruler
  • 1.5mm hex, .050” hex, 1.3mm hex, 0.9mm hex, 4.5mm nut, and PH00 drivers





Manuals/Documents

Setup Sheets



* This vehicle comes as a kit and must be fully assembled by the user. Body, Electronics and/or an engine/motor may be required.

Power Source:
Electric
Terrain:
On-Road
Body Style:
Other
Scale Size:
1:28 Scale
Assembly Level:
Kit (This vehicle comes as a kit and must be fully assembled by the user. See "Required to Complete" for extra items needed.)
Length:
140mm (5.51in)
Width:
varies
Wheelbase:
98mm (3.86in)
Weight:
varies
Internal Gear Ratio:
varies
Drive:
RWD
Product Status:
Active
